Product Overview
EGT N-Type Thermocouple yog ib qho kev ntsuas kub tshwj xeeb uas tsim los rau kev ntsuas qhov kub ntawm cov pa pa (EGT) hauv cov cheeb tsam hnyav. Nrog rau qhov kub thiab txias ntawm -200℃mus rau 1300℃(-}328℃F txog 2372℃F) thiab kev ruaj ntseg tshwj xeeb, nws muab cov ntaub ntawv raug rau kev ua haujlwm zoo ntawm lub cav, kev tswj cov pa phem, thiab kev saib xyuas cov khoom siv. Crafted nrog siab -purity Nicrosil-Nisil alloy conductors, lub thermocouple no muaj superior corrosion kuj, oxidation tsis kam, thiab ntev kev cia siab nyob rau hauv huab cua kub thiab gas ntws tej yam kev mob.
Ntsiab nta
Dav Kub Kub: Ua haujlwm ruaj khov los ntawm -200℃txog 1300 degree, zoo tagnrho rau kev ntsuas kub EGT hauv cov cav, turbines, thiab cov khoom siv hluav taws xob.
Kev ntsuas qhov tseeb: Chav kawm 1 qhov tseeb (± 1.5℃lossis ± 0.4% ntawm tus nqi ntsuas, qhov twg yog qhov loj dua) ua kom ntseeg tau cov ntaub ntawv rau cov ntawv thov tseem ceeb.
Kev tsim kho ntev: Nicrosil-Nisil alloy conductors tiv thaiv corrosion, oxidation, thiab thermal shock; xaiv tau Inconel los yog ceramic tiv thaiv raj txhim khu kev ruaj khov nyob rau hauv qhov hnyav hnyav.
Lub Sijhawm Teb Ceev: Kev sojntsuam zoo tsim kom txo qis thermal huab hwm coj, ua kom pom sai ntawm qhov kub thiab txias (lub sijhawm teb<1 second in gas flow).
Customizable Configurations: Muaj nyob rau hauv ntau yam kev sojntsuam ntev (50mm-500mm), diameters (3mm-8mm), thiab txiav hom (ntsia hlau terminals, connector plugs, liab qab leads) kom haum rau tej installation yuav tsum.
Wide Compatibility: Haum rau cov roj av / diesel xyaw, marine propulsion systems, industrial boilers, gas turbines, thiab pa system tom qab kho.
Loj Specifications
1.N hom thermocouple sojntsuam
2.I chav kawm 1.5℃lossis 0.4% t
3.Probe sheath: Inconel 600
4.Cable khoom: Silicone fiberglass cable nrog thermocouple extension hlau hauv
5.Txoj kev txuas: M16X1.5 lossis M14X1.5 xov
6.Variable txoj kab uas hla: 4.5mm mus rau 1.9mm rau ceev teb.
|
Khoom npe |
EGT N hom thermocouple |
|
Calibration |
K lub N |
|
Qib |
Kuv chav kawm ± 1.5℃lossis 0.4% t |
|
Kev sib txuas |
M14 los yog M16 xov |
|
Ntev |
Qhia tag nrho ntev thiab Immersion ntev |
|
Txoj kab uas hla |
Txo txoj kab uas hla |
|
Kev tiv thaiv |
Inconel 600 |
|
Feature |
Teb ceev ceev |
EGT N hom thermocouple Thermocouple txwv qhov yuam kev
|
Thermoelement |
Hom |
Kev txwv ntawm kev ua yuam kev (± degree) / Qhov ntsuas kub zoo (degree) |
||
|
1 chav |
2 chav |
3 chav |
||
|
NiCr10-NiSi3 |
K |
1.5 lossis 0.4% t / -40 ~ 1000 |
2.5 lossis 0.75% t / -40 ~ 1200 |
2.5 lossis 1.5% t / -40 ~ 200 |
|
NiCrSi-NiSiMg |
N |
1.5 lossis 0.4% t / -40 ~ 1000 |
2.5 lossis 0.75% t / -40 ~ 1200 |
2.5 lossis 1.5% t / -40 ~ 200 |
Daim ntawv thov
Automotive: EGT tshuaj xyuas rau kev ua tau zoo tuning, diesel particulate filter (DPF) regeneration, thiab emissions ua raws.
Marine: Cov pa roj cua ntsuas kub hauv marine cav thiab propulsion systems.
Industrial: Kub tswj hauv boilers, furnaces, gas turbines, thiab industrial burners.
Fais fab Generation: EGT saib xyuas hauv cov tshuab hluav taws xob diesel thiab roj- hluav taws xob hluav taws xob.
Aerospace: Pab pawg fais fab (APU) tso qhov ntsuas kub (tsuas yog siv rau qhov kub thiab txias).
Vim li cas thiaj xaiv Peb EGT N-Hom Thermocouple?
Kev ntseeg siab nyob rau hauv Hnyav tej yam kev mob: Engineered los tiv taus huab cua kub, corrosion, thiab kev co, ua kom lub neej ntev kev pab cuam nyob rau hauv cov pa roj ib puag ncig.
Precision You Can Trust: Chav Kawm 1 raug raws li qhov kev ntsuas nruj tshaj plaws rau kev ua haujlwm kom zoo thiab ua raws li kev nyab xeeb.
Ua raws li koj cov kev xav tau: Customizable sojntsuam qhov ntau thiab tsawg, hom kev txiav tawm, thiab cov ntaub ntawv tiv thaiv ua kom haum rau koj daim ntawv thov.
Tus nqi-Kev Ua tau zoo: Muab kev ua haujlwm zoo dua thiab raug piv rau cov qauv thermocouples, txo cov nqi kho thiab hloov cov nqi.
Cov ntaub ntawv xaj
Peb muab kev pabcuam OEM kom tau raws li koj qhov tshwj xeeb tsim thiab daim ntawv thov. Hu rau peb pab neeg muag khoom rau kev cai quotes, kev txhawb nqa, lossis cov qauv thov.
